Reference [Effects]
ZOOM MRS-802
101
Changing the insert location of the
insert effect
When the project is in its initial state, the insert effect is
applied to the input mixer. However, you may change the
insert location as necessary. The procedure is as follows.
1.
From the main screen, press the [INPUT SOURCE]
key in the effect section.
The currently selected insert location appears on the display.
The following points are available.
• IN
Input mixer (default setting)
• DRUM
Drum kit output
• TR1 - TR8
Track 1 - 8 output
• TR1/2, TR3/4, TR5/6, TR7/8
Track 1/2, 3/4, 5/6, 7/8 output
• MASTER
Immediately before [MASTER] fader
2.
Use the dial to select the insert location.
H INT
While the display of step 1 is shown, you can select the insert
point by pressing the [INPUT 1]/[INPUT 2] keys and the
status keys. To select the track pairs 1/2, 3/4, 5/6, and 7/8,
press two status keys simultaneously.
3.
When the insert point has been selected, press the
[EXIT] key.
The unit returns to the main screen.
H INT
When the insert effect is applied to a point other than the
input mixer, the [INPUT SOURCE] key will be lit at the main
screen.
Selecting the patch for the insert
effect
This section explains how to select the patch for the insert
effect.
1.
Press the [INSERT EFFECT] keys in the display
section.
The key lights up, and the display indicates the patch
currently selected for this algorithm.
To select a patch for the insert effect, start by selecting the
algorithm (effect module combination). When you press the
[INSERT EFFECT] keys, the first line of the display shows
“INSERT” and the second line shows the patch for the insert
effect in this algorithm.
H INT
When the send/return effect was operated, the first line of the
display shows “SEND REV” or “SEND CHO”.
2.
Use the PATCH SELECT [ Q ]/[ W ] keys or turn the
dial to select the patch.
The selected patch becomes active immediately.
Algorithm Patch number
0 – 24
0 – 44
0 – 14
0 – 14
CLEAN
DIST
ACO/BASS SIM
BASS
Algorithm Patch number
0 – 49
0 – 49
0 – 49
0 – 29
MIC
DUAL MIC
LINE
MASTERING
Insert point of insert effect
IN SRC IN SRC
IN
IN
Effect type
Patch name Patch number
INSERT INSERT
MRS-Drv
MRS-Drv 1
