System Configuration

2–36

976-0043-01-02

Generator-Only Systems

In these applications, an AC generator serves as the main AC source
when batteries are insufficient to power the loads. Both an AC and a DC
generator can provide a power source for the battery charger. With the aid
of the Xantrex Generator Start Module (GSM), the

Sine Wave Plus

can

turn on automatically most remote-starting generators, on demand.

See

“Generator Considerations” on page 2–19

and

Appendix D,

“Generators”

for additional information regarding using generators for

system input.

Single-Inverter Configurations

A single-inverter system is usually adequate to power most 120 Vac
loads. If 240 Vac is required from the system and doesn’t exceed the
wattage output of a single inverter, a step-up autotransformer can be
added to the output of the system to increase the voltage output.

See

Figure 2-19

for an illustration of a 120 Vac generator-only system

using a single inverter. Disregard any part of this illustration that does not
apply to the system configuration being installed.
