User Menu Settings

976-0043-01-02

B–3

Ph 1-800-446-6180
www.xantrex.com

Press reset for factory defaults

Press to refresh the LCD display.

04 Meters Menu

See

“04 Meters Menu” on page 8–22

for details.

04A Battery Actual VDC

13.2 to 35.5

Read Only

20.0 to 71.0

Read Only

04B Battery Comp VDC

13.2 to 35.5

Read Only

20.0 to 71.0

Read Only

04C Inv/Chr Amps AC

-63 to 63

Read Only

-63 to 63

Read Only

04D Input Amps AC

00 to 63

Read Only

00 to 63

Read Only

04E Load Amps AC

00 to 63

Read Only

00 to 63

Read Only

04F Inverter Volts AC

00 to 163

Read Only

00 to 163

Read Only

04G Grid (AC1) Volts AC

00 to 163

Read Only

00 to163

Read Only

04H Gen (AC2) Volts AC

00 to 163

Read Only

00 to 163

Read Only

04I Frequency Hertz

52 to 68

Read Only

52 to 68

Read Only

04J Max Bulk/EQ Time h:m

00:00 to
23:50

Read Only

00:00 to
23:50

Read Only

04K Battery Temp Degrees C

-28 to 60, OL Read Only

-28 to 60, OL Read Only

04L Fan Speed

00, 01, 02,
03, 04

Read Only

00, 01, 02,
03, 04

Read Only

05 Error Causes Menu

See

“05 Error Causes Menu” on page 8–25

for details.

05A Over Current

NO YES

Read Only

NO YES

Read Only

05B Transformer overtemp

NO YES

Read Only

NO YES

Read Only

05C Heatsink overtemp

NO YES

Read Only

NO YES

Read Only

05D Low Battery Voltage

NO YES

Read Only

NO YES

Read Only

05E High Battery Voltage

NO YES

Read Only

NO YES

Read Only

05F External err (stacked)

NO YES

Read Only

NO YES

Read Only

05G Input Relay Failure

NO YES

Read Only

NO YES

Read Only

05H Gen Failed to Start

NO YES

Read Only

NO YES

Read Only

05I Gen Stopped due to V/F

NO YES

Read Only

NO YES

Read Only

Table B-1 User Menu Default and User Settings

User Menus

Sine Wave Plus

2524 and 4024

Sine Wave Plus

2548, 4048, and 5548

User

Settings

Range/

Display

Default

Settings

Range/

Display

Default

Settings
