Figure 1-1 the sine wave plus, Front panel, Figure 1-2 the front side of the sine wave plus – Xantrex Technology SW Plus 4024 User Manual

Page 29: Front panel –3, Figure 1-1, Figure 1-2, The front side of the

Basic Features

976-0043-01-02

1–3

Front Panel

The front of the

Sine Wave Plus

has the following features:

•

the Inverter Control Module (ICM) Display

•

the AC Access Cover

Figure 1-1 The

Sine Wave Plus

Figure 1-2 The Front Side of the

Sine Wave Plus

AC Access Cover

Inverter Control Module Display
