Advanced Setup
7–4 976-0043-01-02
25A RY7 Mode GS RN1 RN2 GS GS RN1 RN2 GS page 7–30
25B Gen Warm-up
Second/Minute 0 to 127
/0 to 127 10
Seconds 0 to 127
/0 to 127 10
Seconds page 7–37
25C Pre Crank Seconds 00 to 255 10 00 to 255 10 page 7–37
25D Max Cranking Seconds 01 to 15 10 01 to 15 10 page 7–37
25E Post Crank Seconds 00 to 255 30 00 to 255 30
End Menu 25
26 Gen Auto Run Setup Menu See “26 Gen Auto Run Setup Menu” on page 7–38 for details.
26A Load Start Amps AC 00 to 63 20 00 to 63 20 page 7–38
26B Load Start Delay Min 00.0 to 25.5 05.0 00.0 to 25.5 05.0 page 7–38
26C Load Stop Delay Min 00.0 to 25.5 05.0 00.0 to 25.5 05.0 page 7–38
26D 24 hr Start Volts DC 10.0 to 35.5 24.6 20.0 to 71.0 49.2 page 7–38
26E 2 hr Start Volts DC 10.0 to 35.5 23.6 20.0 to 71.0 47.2 page 7–38
26F 15 min Start Volts DC 10.0 to 35.5 22.6 20.0 to 71.0 45.2 page 7–39
26G Read LBCO 30 sec Start LBCO setting
(11C) 22.0
Read Only LBCO setting
(11C) 44.0
Read Only page 7–39
End Menu 26
27 Save/Restore Settings Menu See “27 Save/Restore Settings Menu” on page 7–39 for details.
27A Push INV now to save
Settings Push INV now to Save Settings page 7–39
27B Push GEN to restore
settings Push GEN to restore settings page 7–40
27C Push GEN for factory
defaults Push GEN for factory defaults page 7–40
End Menu 27
END ADVANCED SETUP
MENU
Table 7-1 Advanced Setup Default Settings for the Sine Wave Plus 2524 and 2548 Models
Advanced Setup Menus
Sine Wave Plus 2524 Sine Wave Plus 2548
See Page Range/Display
Default
Settings
Range/Display
Default
Settings
