Operation

8–8

976-0043-01-02

Error LED Reset

Reset

To reset the inverter after resolving an error condition, press the red INV
button (INVERTER ON/OFF Menu) and select OFF and then ON with
the SET POINT buttons.

STATUS LED
(Yellow)

The STATUS LED illuminates to indicate various conditions of the
inverter/charger. This is not an error condition, but an indication that the
inverter/charger is in a special mode or condition (i.e., such as Bypass
Mode, Charger-only Mode, Generator Cooldown Period etc.)

Status conditions include:

Bypass Mode was selected (06A)

Charger only (CHR) was selected (06B)

Generator was signaled to run (06C)

Generator is in cooldown (06D)

EQ charge is selected (06E)

Battery Vdc is less than the LBCO (06F)

Battery Vdc is greater than the HBCO (06G)

EPO Shutdown command was received (06H)

For a complete description of the Status Menus, see

“06 Status Menu” on

page 8–28

.
