Mechanical Specifications
976-0043-01-02
A–5
Mechanical
Specifications
Sine Wave Plus
4024
Sine Wave Plus
4048
Sine Wave Plus
5548
Operating
Temperature Range
SPECIFIED
(will meet specified
tolerances)
32 °F to 77 °F
(0 °C to 25 °C)
32 °F to 77 °F
(0 °C to 25 °C)
32 °F to 77 °F
(0 °C to 25 °C)
ALLOWED
(may not meet
specified tolerances)
-13 °F to 140 °F
(-25 °C to 60 °C)
-13 °F to 140 °F
(-25 °C to 60 °C)
-13 °F to 140 °F
(-25 °C to 60 °C)
NON-OPERATING
(storage)
-67 °F to 284 °F
(-55 °C to 140 °C)
-67 °F to 284 °F
(-55 °C to 140 °C)
-67 °F to 284 °F
(-55 °C to 140 °C)
Enclosure Type
Indoor, ventilated,
Galvaneel steel chassis
with powder coat finish
Indoor, ventilated,
Galvaneel steel chassis
with powder coat finish
Indoor, ventilated,
Galvaneel steel chassis
with powder coat finish
Unit Weight
117 lb (53 kg)
117 lb (53 kg)
136 lb (62 kg)
Shipping Weight
126 lb (57 kg)
126 lb (57 kg)
145 lb (66 kg)
Inverter Dimensions
(H x W x D)
15 1/8" x 21" x 8 7/8"
(38 cm x 53 cm x 22 cm)
15 1/8" x 21" x 8 7/8"
(38 cm x 53 cm x 22 cm)
15 1/8" x 21" x 8 7/8"
(38 cm x 53 cm x 22 cm)
Shipping Dimensions
(H x W x D)
20" x 27 7/8" x 14 1/4"
(51 cm x 71 cm x 36 cm)
20" x 27 7/8" x 14 1/4"
(51 cm x 71 cm x 36 cm)
20" x 27 7/8" x 14 1/4"
(51 cm x 71 cm x 36 cm)
Mounting
Wall or Shelf Mount
Wall or Shelf Mount
Wall or Shelf Mount
See Certification Label for specific regulatory agency approval information.
