Advanced Setup Summary
976-0043-01-02 7–9
26A Load Start Amps AC 00 to 63 45 page 7–38
26B Load Start Delay Min 00.0 to 25.5 05.0 page 7–38
26C Load Stop Delay Min 00.0 to 25.5 05.0 page 7–38
26D 24 hr Start Volts DC 20.0 to 71.0 49.2 page 7–38
26E 2 hr Start Volts DC 20.0 to 71.0 47.2 page 7–38
26F 15 min Start Volts DC 20.0 to 71.0 45.2 page 7–39
26G Read LBCO 30 sec Start LBCO setting
(11C) 44.0
Read
Only page 7–39
End Menu 26
27 Save/Restore Settings Menu See “27 Save/Restore Settings Menu” on page 7–39 for details.
27A Push INV now to save
Settings Push INV now to Save
Settings
page 7–39
27B Push GEN to restore settings Push GEN to restore settings page 7–40
27C Push GEN for factory defaults Push GEN for factory
defaults
page 7–40
End Menu 27
END ADVANCED SETUP MENU
Table 7-3 Advanced Setup Default Settings for the Sine Wave Plus Plus 5548 Models
Advanced Setup Menus
Sine Wave Plus 5548
See Page Range/Display
Default
Settings
