Configuration Settings
B–6 976-0043-01-02
12I Temp Comp LeadAcid
NiCad LeadAcid LeadAcid
NiCad LeadAcid
13 AC Inputs Menu See “13 AC Inputs Menu” on page 6–26 for details.
13A Grid (AC1) Amps AC 00 to 60 60 00 to 60 60
13B Gen (AC2) Amps AC 00 to 60 30 00 to 60 30
13C Input Upper Limit Vac 125 to 150 130 125 to 150 130
13D Input Lower Limit Vac 80 to 115 110 80 to 115 110
14 Save/Restore Settings Menu See “14 Save/Restore Settings Menu” on page 6–29 for details.
14A Push INV now to save
settings Push INV now to Save Settings
14B Push GEN to restore settings Push GEN to restore settings
14C Push GEN for factory
defaults Push GEN for factory defaults
Table B-3 Basic Setup Default and User Settings for the Sine Wave Plus 4024 and 4048 Models
Sine Wave Plus 4024 Sine Wave Plus 4048
User
Settings Basic Setup Menus
Range/
Display Default
Range/
Display Default
10 Time of Day Setup Menu See “10 Time of Day Setup Menu” on page 6–11 for details.
10A Set Hour 00:00:00 to
23:50:00 00:00:00 00:00:00 to
23:50:00 00:00:00
10B Set Minute 00:00:00 to
00:09:00 00:00:00 00:00:00 to
00:09:00 00:00:00
10C Set Second 00 to 59 00:00:00 00 to 59 00:00:00
11 Inverter Setup Menu See “11 Inverter Setup Menu” on page 6–12 for details.
11A High Battery Cut Out Vdc 16.1 to 34.0 32.0 32.2 to 68.0 64.0
11B Low Battery Cut In Vdc 16.1 to 33.9 26.0 32.2 to 67.8 52.0
11C Low Battery Cut Out Vdc 11.0 to 33.9 22.0 32.0 to 67.8 44.0
11D LBCO Delay Minutes 01 to 255 15 01 to 255 15
11E Search Watts (SRCH) 00 to 248 08 00 to 248 08
Table B-2 Basic Setup Default and User Settings for the Sine Wave Plus 2524 and 2548 Models
Sine Wave Plus 2524 Sine Wave Plus 2548
User
Settings Basic Setup Menus
Range/
Display Default
Range/
Display Default
