Basic Setup Programming
6–10 976-0043-01-02
Accessing the Basic Setup Menu
To access the Basic Setup Menu:
1. If you have not already done so, turn on the inverter.
2. Press the button to move forward within the Menu Headings until
the END USER MENU is displayed.
3. Press and hold down the green GEN button.
4. While holding the green GEN button down, press the red INV button
to move into the Basic Setup Menu.
Figure 6-1 Accessing the Basic Setup Menu
While holding the green GEN
button down, press the red INV
button to move into the Basic
Setup Menu.
Press the Menu Heading button
until the END USER MENU is
displayed.
Press and hold down the
green GEN button.
Power up Display
