Operation
8–12 976-0043-01-02
Xantrex Tech Inc
5916 195th St NE Info.
Displayed Read Only Info.
Displayed Read Only page 8–20
Arlington, WA
98223 USA Info.
Displayed Read Only Info.
Displayed Read Only page 8–20
Ph 1-800-446-6180
www.xantrex.com Info.
Displayed Read Only Info.
Displayed Read Only page 8–20
Press reset for factory defaults Press to refresh the LCD display. page 8–21
End Menu 03 Info.
Displayed Read Only Info.
Displayed Read Only
04 Meters Menu See “04 Meters Menu” on page 8–22 for details.
04A Battery Actual VDC 13.2 to 35.5 Read Only 20.0 to 71.0 Read Only page 8–22
04B Battery Comp VDC 13.2 to 35.5 Read Only 20.0 to 71.0 Read Only page 8–23
04C Inv/Chr Amps AC -63 to 63 Read Only -63 to 63 Read Only page 8–23
04D Input Amps AC 00 to 63 Read Only 00 to 63 Read Only page 8–23
04E Load Amps AC 00 to 63 Read Only 00 to 63 Read Only page 8–23
04F Inverter Volts AC 00 to 163 Read Only 00 to 163 Read Only page 8–23
04G Grid (AC1) Volts AC 00 to 163 Read Only 00 to163 Read Only page 8–24
04H Gen (AC2) Volts AC 00 to 163 Read Only 00 to 163 Read Only page 8–24
04I Frequency Hertz 52 to 68 Read Only 52 to 68 Read Only page 8–24
04J Max Bulk/EQ Time him 00:00 to
23:50 Read Only 00:00 to
23:50 Read Only page 8–24
04K Battery Temp Degrees C -28 to 60, OL Read Only -28 to 60, OL Read Only page 8–24
04L Fan Speed 00, 01, 02,
03, 04 Read Only 00, 01, 02,
03, 04 Read Only page 8–24
End Menu 04
05 Error Causes Menu See “05 Error Causes Menu” on page 8–25 for details.
05A Over Current NO YES Read Only NO YES Read Only page 8–25
05B Transformer overtemp NO YES Read Only NO YES Read Only page 8–25
05C Heatsink overtemp NO YES Read Only NO YES Read Only page 8–26
05D Low Battery Voltage NO YES Read Only NO YES Read Only page 8–26
05E High Battery Voltage NO YES Read Only NO YES Read Only page 8–27
Table 8-2 User Menu
User Menus
Sine Wave Plus
2524 and 4024
Sine Wave Plus
2548,4048, and 5548
See Page
Range/
Display Default
Settings Range/
Display Default
Settings
