Chapter 6 ARP Inspection Commands
Ethernet Switch CLI Reference Guide
38
The following table describes the labels in this screen.
This example displays whether ports are trusted or untrusted ports for ARP inspection.
The following table describes the labels in this screen.
Table 20 show arp inspection log
LABEL
DESCRIPTION
Total Log Buffer Size
This field displays the maximum number (1-1024) of log messages that
were generated by ARP packets and have not been sent to the syslog
server yet.
If the number of log messages in the Switch exceeds this number, the
Switch stops recording log messages and simply starts counting the
number of entries that were dropped due to unavailable buffer.
Syslog rate
This field displays the maximum number of syslog messages the Switch
can send to the syslog server in one batch. This number is expressed as a
rate because the batch frequency is determined by the Log Interval.
Port
This field displays the source port of the ARP packet.
Vlan
This field displays the source VLAN ID of the ARP packet.
Sender MAC
This field displays the source MAC address of the ARP packet.
Sender IP
This field displays the source IP address of the ARP packet.
Pkts
This field displays the number of ARP packets that were consolidated into
this log message. The Switch consolidates identical log messages
generated by ARP packets in the log consolidation interval into one log
message.
Reason
This field displays the reason the log message was generated.
static deny: An ARP packet was discarded because it violated a static
binding with the same MAC address and VLAN ID.
deny: An ARP packet was discarded because there were no bindings with
the same MAC address and VLAN ID.
static permit: An ARP packet was forwarded because it matched a static
binding.
Time
This field displays when the log message was generated.
Total number of logs
This field displays the number of log messages that were generated by
ARP packets and that have not been sent to the syslog server yet. If one or
more log messages are dropped due to unavailable buffer, there is an entry
called overflow with the current number of dropped log messages.
sysname# show arp inspection interface port-channel 1
Interface Trusted State Rate (pps) Burst Interval
--------- ------------- ---------- --------------
1 Untrusted 15 1
Table 21 show arp inspection interface port-channel
LABEL
DESCRIPTION
Interface
This field displays the port number. If you configure the * port, the settings
are applied to all of the ports.
Trusted State
This field displays whether this port is a trusted port (Trusted) or an
untrusted port (Untrusted).
Trusted ports are connected to DHCP servers or other switches, and the
switch discards DHCP packets from trusted ports only if the rate at which
DHCP packets arrive is too high.
