Chapter 65 trTCM Commands
Ethernet Switch CLI Reference Guide
228
65.3 Command Examples
This example activates trTCM on the Switch with the following settings:
• Sets the Switch to inspect the DSCP value of the packets (color-aware mode).
• Enables trTCM on ports 1-5.
• Sets the Committed Information Rate (CIR) to 4000 Kbps.
• Sets the Peak Information Rate (PIR) to 4500 Kbps.
• Specifies DSCP value 7 for green packets, 22 for yellow packets and 44 for red packets.
trtcm dscp yellow <0-63> Specifies the DSCP value to use for
packets with medium packet loss priority.
C 13
trtcm dscp red <0-63> Specifies the DSCP value to use for
packets with high packet loss priority.
C 13
Table 137 trtcm Command Summary (continued)
COMMAND DESCRIPTION M P
sysname(config)# trtcm
sysname(config)# trtcm mode color-aware
sysname(config)# interface port-channel 1-5
sysname(config-interface)# trtcm
sysname(config-interface)# trtcm cir 4000
sysname(config-interface)# trtcm pir 4500
sysname(config-interface)# trtcm dscp green 7
sysname(config-interface)# trtcm dscp yellow 22
sysname(config-interface)# trtcm dscp red 44
sysname(config-interface)# exit
sysname(config)# exit
sysname# show running-config interface port-channel 1 trtcm
Building configuration...
Current configuration:
interface port-channel 1
trtcm
trtcm cir 4000
trtcm pir 4500
trtcm dscp green 7
trtcm dscp yellow 22
trtcm dscp red 44
exit
