Chapter 9 WISP Mode

NBG-419N User’s Guide

82

The following table describes the labels shown in the Status screen.

Table 29 Status Screen: WISP Mode

LABEL

DESCRIPTION

Logout

Click this at any time to exit the Web Configurator.

Device Information
Host Name

This is the System Name you enter in the Maintenance > General
screen. It is for identification purposes.

Firmware Version

This is the firmware version and the date created.

Sys OP Mode

This is the device mode (

Section 5.1.2 on page 49

) to which the NBG-

419N is set - WISP Mode.

WAN Information
- MAC Address

This shows the WAN Ethernet adapter MAC Address of your device.

- IP Address

This shows the WAN port’s IP address.

- IP Subnet Mask

This shows the WAN port’s subnet mask.

- Default Gateway

This shows the WAN port’s gateway IP address.

- DHCP

This shows the LAN port’s DHCP role - Client or Server.

LAN Information
- MAC Address

This shows the LAN Ethernet adapter MAC Address of your device.

- IP Address

This shows the LAN port’s IP address.

- IP Subnet Mask

This shows the LAN port’s subnet mask.

- DHCP

This shows the LAN port’s DHCP role - Server or None.

WLAN Information
- WLAN OP Mode

This is the device mode (

Section 5.1.2 on page 49

) to which the NBG-

419N’s wireless LAN is set - Access Point Mode.

- MAC Address

This shows the wireless adapter MAC Address of your device.

- Status

This shows the current status of the Wireless LAN - ON or OFF.

- Name (SSID)

This shows a descriptive name used to identify the NBG-419N in the
wireless LAN.

- Connect Status

This shows whether or not the NBG-419N has successfully associated with
an access point - Connected or Disassociated.

- Security Mode

This shows the level of wireless security the NBG-419N is using.

- 802.11 Mode

This shows the wireless standard.

System Status
Item

This column shows the type of data the NBG-419N is recording.

Data

This column shows the actual data recorded by the NBG-419N.

System Up Time

This is the total time the NBG-419N has been on.

Current Date/Time

This field displays your NBG-419N’s present

date and time.

System Resource
