NBG-419N User’s Guide
171
C
H A P T E R
21
Bandwidth Management
21.1 Overview
This chapter contains information about configuring bandwidth management and
editing rules.
ZyXEL’s Bandwidth Management allows you to specify bandwidth management
rules based on an application.
In the figure below, uplink traffic goes from the LAN device (A) to the WAN device
(B). Bandwidth management is applied before sending the packets out to the
WAN. Downlink traffic comes back from the WAN device (B) to the LAN device
(A). Bandwidth management is applied before sending the traffic out to LAN.
Figure 105 Bandwidth Management Example
You can allocate specific amounts of bandwidth capacity (bandwidth budgets) to
individual applications (like VoIP, Web, FTP, and E-mail for example).
21.2 What You Can Do
• Use the General screen (
) to enable bandwidth
management and assign bandwidth values.
A
B
-> VOIP
-> FTP
-> HTTP
-> Chat, Email
