Chapter 11 Wireless LAN
NBG-419N User’s Guide
115
11.11 WDS Screen
A Wireless Distribution System is a wireless connection between two or more APs.
Use this screen to set the operating mode of your NBG-419N to AP + Bridge or
Bridge Only and establish wireless links with other APs. You need to know the
MAC address of the peer device, which also must be in bridge mode.
Note: You must enable the same wireless security settings on the NBG-419N and on
all wireless clients that you want to associate with it.
Click Network > Wireless LAN > WDS tab. The following screen opens with the
Basic Setting set to Disabled, and Security Mode set to No Security.
Figure 77 Network > Wireless LAN > WDS
For the
following times
(24-Hour
Format) Select a begin time using the first set of hour and minute (min) drop
down boxes and select an end time using the second set of hour and
minute (min) drop down boxes. If you have chosen On earlier for the
WLAN Status the Wireless LAN will turn on between the two times you
enter in these fields. If you have chosen Off earlier for the WLAN Status
the Wireless LAN will turn off between the two times you enter in these
fields.
Apply Click Apply to save your changes back to the NBG-419N.
Reset Click Reset to reload the previous configuration for this screen.
Table 45 Network > Wireless LAN > Scheduling
LABEL DESCRIPTION
