Chapter 21 Bandwidth Management
NBG-419N User’s Guide
178
See Appendix E on page 277 for commonly used services and port numbers.
21.6 Monitor Screen
Use this screen to view the amount of network bandwidth that applications
running in the network are using.
The bandwidth is measured in kilobits per second (kbps).
The monitor shows what kinds of applications are running in the network, the
maximum kbps that each application can use, as well as the percentage of
bandwidth it is using.
Figure 110 Management > Bandwidth Management > Monitor
Protocol Select the protocol (TCP, UDP, User defined) for which the bandwidth
management rule applies.
If you select User-defined, enter the protocol for which the bandwidth
management rule applies. For example, ICMP for ping traffic.
Apply Click Apply to save your customized settings.
Cancel Click Cancel to exit this screen without saving.
LABEL DESCRIPTION
