Page 172
Chapter 21 Bandwidth Management
NBG-419N User’s Guide
172
• Use the Advanced screen (
) to configure bandwidth
managements rule for the pre-defined services and applications.
• Use the Monitor screen (
) to view the amount of
network bandwidth that applications running in the network are using.
21.3 What You Need To Know
The sum of the bandwidth allotments that apply to the WAN interface (LAN to
WAN, WLAN to WAN) must be less than or equal to the Upstream Bandwidth
that you configure in the Bandwidth Management Advanced screen (
).
The sum of the bandwidth allotments that apply to the LAN interface (WAN to
LAN, WAN to WLAN) must be less than or equal to the Downstream Bandwidth
that you configure in the Bandwidth Management Advanced screen
.
21.4 General Screen
Use this screen to have the NBG-419N apply bandwidth management.
Click Management > Bandwidth MGMT to open the bandwidth management
General screen.
Figure 106 Management > Bandwidth Management > General
