ZyXEL Communications NBG-419N - Manual (Page 123)

Chapter 12 WAN
NBG-419N User’s Guide
123
This screen displays when you select PPPoE encapsulation.
Figure 81 Network > WAN > Internet Connection: PPPoE Encapsulation
The following table describes the labels in this screen.
Table 48 Network > WAN > Internet Connection: PPPoE Encapsulation
LABEL DESCRIPTION
ISP Parameters for Internet Access
Encapsulation
Select PPP over Ethernet if you connect to your Internet via dial-up.
User Name Type the user name given to you by your ISP.
Password Type the password associated with the user name above.
Retype to
Confirm Type your password again to make sure that you have entered is
correctly.
MTU Size Enter the Maximum Transmission Unit (MTU) or the largest packet size
per frame that your NBG-419N can receive and process.
Nailed-Up
Connection Select Nailed-Up Connection if you do not want the connection to time
out.
