NBG-419N User’s Guide
151
C
H A P T E R
17
Static Route
17.1 Overview
This chapter shows you how to configure static routes for your NBG-419N.
Each remote node specifies only the network to which the gateway is directly
connected, and the NBG-419N has no knowledge of the networks beyond. For
instance, the NBG-419N knows about network N2 in the following figure through
remote node Router 1. However, the NBG-419N is unable to route a packet to
network N3 because it doesn't know that there is a route through the same
remote node Router 1 (via gateway Router 2). The static routes are for you to tell
the NBG-419N about the networks beyond the remote nodes.
Figure 98 Example of Static Routing Topology
17.2 What You Can Do
Use the IP Static Route screen ( Section 17.3 on page 152 ) to view, add and
delete routes.
