Chapter 11 Wireless LAN
NBG-419N User’s Guide
112
11.8 WPS Screen
Use this screen to enable/disable WPS, view or generate a new PIN number and
check current WPS status. To open this screen, click Network > Wireless LAN >
WPS tab.
Figure 74 Network > Wireless LAN > WPS
The following table describes the labels in this screen.
Table 43 Network > Wireless LAN > WPS
LABEL DESCRIPTION
WPS Setup
Enable WPS
Select this to enable the WPS feature.
PIN Number This displays a PIN number last time system generated. Click Generate
to generate a new PIN number.
Status
Status
This displays Configured when the NBG-419N has connected to a
wireless network using WPS or when Enable WPS is selected and
wireless or wireless security settings have been changed. The current
wireless and wireless security settings also appear in the screen.
This displays Unconfigured if WPS is disabled and there are no
wireless or wireless security changes on the NBG-419N or you click
Release_Configuration to remove the configured wireless and
wireless security settings.
Release
Configuration This button is only available when the WPS status displays Configured.
Click this button to remove all configured wireless and wireless security
settings for WPS connections on the NBG-419N.
802.11 Mode This is the 802.11 mode used. Only compliant WLAN devices can
associate with the NBG-419N.
SSID This is the name of the wireless network.
Security This is the type of wireless security employed by the network.
