Chapter 12 WAN
NBG-419N User’s Guide
128
This screen displays when you select L2TP encapsulation.
Figure 83 Network > WAN > Internet Connection: L2TP Encapsulation
The following table describes the labels in this screen.
Table 50 Network > WAN > Internet Connection: L2TP Encapsulation
LABEL DESCRIPTION
ISP Parameters for Internet Access
Connection Type
To configure a L2TP client, you must configure the User Name and
Password fields for a layer-2 connection and the L2TP parameters
for an L2TP connection.
User Name Type the user name given to you by your ISP.
Password Type the password associated with the User Name above.
Retype to Confirm Type your password again to make sure that you have entered is
correctly.
L2TP Configuration
Server IP Address
Type the IP address of the L2TP server.
Get automatically
from ISP Select this option If your ISP did not assign you a fixed IP address.
This is the default selection.
