Chapter 12 WAN
NBG-419N User’s Guide
129
Use Fixed IP
Address
Select this option If the ISP assigned a fixed IP address.
IP Address
Enter your WAN IP address in this field if you selected Use Fixed IP
Address.
IP Subnet Mask
Your NBG-419N will automatically calculate the subnet mask based
on the IP address that you assign. Unless you are implementing
subnetting, use the subnet mask computed by the NBG-419N.
Gateway IP
Address
Enter a Gateway IP Address (if your ISP gave you one) in this
field.
WAN IP Address Assignment
Get automatically
from ISP
Select this to get your WAN IP address from your ISP.
Use Fixed IP
Address
Select this option If the ISP assigned a fixed IP address.
My WAN IP
Address
Enter your WAN IP address in this field if you selected Use Fixed IP
Address.
WAN DNS Assignment
First DNS Server
Second DNS Server
Select From ISP if your ISP dynamically assigns DNS server
information (and the NBG-419N's WAN IP address). The field to the
right displays the (read-only) DNS server IP address that the ISP
assigns.
Select User-Defined if you have the IP address of a DNS server.
Enter the DNS server's IP address in the field to the right. If you
chose User-Defined, but leave the IP address set to 0.0.0.0, User-
Defined changes to None after you click Apply. If you set a second
choice to User-Defined, and enter the same IP address, the
second User-Defined changes to None after you click Apply.
Select None if you do not want to configure DNS servers. If you do
not configure a DNS server, you must know the IP address of a
computer in order to access it.
WAN MAC Address
The MAC address section allows users to configure the WAN port's
MAC address by either using the NBG-419N’s MAC address, copying
the MAC address from a computer on your LAN or manually entering
a MAC address.
Factory default
Select Factory default to use the factory assigned default MAC
Address.
Clone the
computer’s MAC
address - IP
Address
Select Clone the computer's MAC address - IP Address and
enter the IP address of the computer on the LAN whose MAC you
are cloning.
Set WAN MAC
Address
Select this option and enter the MAC address you want to use.
Apply
Click Apply to save your changes back to the NBG-419N.
Reset
Click Reset to begin configuring this screen afresh.
Table 50 Network > WAN > Internet Connection: L2TP Encapsulation
LABEL
DESCRIPTION
