TMP92CM22
2007-02-16 92CM22-93
BEXCSL
7 6 5 4 3 2 1 0
Bit symbol BEXWW2 BEXWW1 BEXWW0 BEXWR2 BEXWR1 BEXWR0
Read/Write W W
After reset 0 1 0 0 1 0
BEXWW[2:0] Specifies the number of write waits.
001 = 2 states (0 waits) access 010 = 3 states (1 wait) access
101
= 4 states (2 waits) access
110
= 5 states (3 waits) access
111
= 6 states (4 waits) access
011
=
WAIT pin input mode
Others
= (Reserved)
BEXWR[2:0] Specifies the number of read waits.
001 = 2 states (0 waits) access 010 = 3 states (1 wait) access
101
= 4 states (2 waits) access
110
= 5 states (3 waits) access
111
= 6 states (4 waits) access
011
=
WAIT pin input mode
Others
= (Reserved)
BEXCSH
7 6 5 4 3 2 1 0
Bit Symbol
− − − BEXOM1
BEXOM0 BEXBUS1 BEXBUS0
Read/Write W W
After reset Always write 0. 0 0 0 0
BEXOM[1:0]
00
= SRAM or ROM (Default)
01 = (Reserved)
10
= (Reserved)
11 = (Reserved)
BEXBUS[1:0]
00 = 8 bits (Default)
01
= 16 bits
10
= (Reserved)
11
= (Reserved)
