TMP92CM22
2007-02-16 92CM22-147
• Integer divider (N divider)
For example, when the f
C
= 39.3216 MHz, the input clock frequency = φT2, the
frequency divider N (BR0CR) = 8, and BR0CR = 0, the
baud rate in UART mode is as follows:
∗ Clock state
Clock gear: 1/1 (f
C
)
f
C
/32
8
= 39.3216 Ч 10 6 ч 16 ч 8 ч 16 = 9600 (bps)
Note: The N
+ (16 − K)/16 division function is disabled and setting BR0ADD
is invalid.
• N + (16 − K)/16 divider (UART mode only)
Accordingly, when f
C
= 31.9488 MHz, the input clock frequency = φT2, the
frequency divider N (BR0CR) = 6, K (BR0ADD) = 8, and
BR0CR = 1, the baud rate is as follows:
* Clock state
Clock gear: 1/1 (f
C
)
f
C
/32
(16
− 8)
16
= 31.9488 Ч 10 6 ч 32 ч (6 + ) ч 16 = 9600 (bps)
Table 3.9.3 show examples of UART mode transfer rates.
Additionally, the external clock input is available in the serial clock (Serial
channels 0 and 1). The method for calculating the baud rate is explained below:
• In UART mode
Baud rate
= External clock input frequency ÷ 16
It is necessary to satisfy (External clock input cycle)
≥ 4/f
SYS
• In I/O interface mode
Baud rate
= External clock input frequency
It is necessary to satisfy (External clock input cycle)
≥ 16/f
SYS
Baud rate
= ч 16
8
16
ч 16
6
+
Baud rate
=
