TMP92CM22
2007-02-16 92CM22-203
AD Conversion Result Register 2 Low
7 6 5 4 3 2 1 0
Bit symbol ADR21 ADR20 ADR2RF ADREG2L
(12A4H)
Read/Write R R
After reset Undefined 0
Function Stores lower 2 bits of AD
conversion result.
AD conversion
data storage
flag
1: Conversion
result stored
AD Conversion Result Register 2 High
7 6 5 4 3 2 1 0
Bit symbol ADR29 ADR28 ADR27 ADR26 ADR25 ADR24 ADR23 ADR22 ADREG2H
(12A5H)
Read/Write R
After reset Undefined
Function Stores upper 8 bits of AD conversion result.
AD Conversion Result Register 3 Low
7 6 5 4 3 2 1 0
Bit symbol ADR31 ADR30 ADR3RF ADREG3L
(12A6H)
Read/Write R R
After reset Undefined 0
Function Stores lower 2 bits of AD
conversion result.
AD conversion
data storage
flag
1: Conversion
result stored
AD Conversion Result Register 3 High
7 6 5 4 3 2 1 0
Bit symbol ADR39 ADR38 ADR37 ADR36 ADR35 ADR34 ADR33 ADR32 ADREG3H
(12A7H)
Read/Write R
After reset Undefined
Function Stores upper 8 bits of AD conversion result.
9 8 7 6 5 4 3 2 1 0
7 6 5 4 3 2 1 0 7 6 5 4 3 2 1 0
Figure 3.11.5 Register for AD Converter
Channel × conversion
result
ADREGxL
•
Bits 5 to 1 are always read as 1.
• Bit0 is the AD conversion data storage flag . When the AD
conversion result is stored, the flag is set to 1. When either of the
registers (ADREGxH, ADREGxL) is read, the flag is cleared to 0.
ADREGxH
