TMP92CM22
2007-02-16 92CM22-162
Bit0 Bit1 Bit6 Bit5
SCLK0 input
(
= 0
rising mode)
SCLK0 input
(
= 1
falling mode)
TXD0
ITX0C
(INTTX0 interrupt
request)
1. Transmission
In SCLK output mode 8-bit data and a synchronous clock are output on the
TXD0 and SCLK0 pins respectively each time the CPU writes the data to the
transmission buffer. When all data is outputted, INTES0 will be set to
generate the INTTX0 interrupt.
Figure 3.9.19 Transmission Operation in I/O Interface Mode (SCLK0 output mode)
In SCLK input mode, 8-bit data is output from the TXD0 pin when the SCLK0
input becomes active after the data has been written to the transmission buffer by
the CPU.
When all data is outputted, INTES0 will be set to generate INTTX0
interrupt.
Figure 3.9.20 Transmission Operation in I/O Interface Mode (SCLK0 input mode)
Bit7
SCLK0 output
(
= 0
rising mode)
Bit7 Bit0 Bit1 Bit6
Timing of writing
transmission data
TXD0
ITX0C
(INTTX0 interrupt
request)
SCLK0 output
(
= 1
falling mode)
(Internal clock
timinig)
