TMP92CM22
2007-02-16 92CM22-195
Figure 3.10.25 Transmission Mode
Example: Program to stop data transmission (when an external clock is used)
STEST1 : BIT 2, (SBI0SR) ; If
= 1 then loop.
JR NZ, STEST1
STEST2 : BIT 0, (P9) ; If SCK
= 0 then loop.
JR Z, STEST2
LD (SBI0CR1), 00000111B ;
← 0
b
b7 *
(a) Internal clock
a2 a1 a4 a3 a6 a5 b0 a7 b2 b1 b4 b3 b6 b5 a0
Clear
SCK pin (Output)
a
Writing transmission data
SO pin
INTSBE0
interrupt request
SBI0DBR
(b) External clock
Clear
SCK pin (Input)
Writing transmission data
SO pin
INTSBE0
interrupt request
SBI0DBR
b7 * a2 a1 a4 a3 a6 a5 b0 a7 b2 b1 b4 b3 b6 b5 a0
b a
