TMP92CM22
2007-02-16
92CM22-205
AD Conversion Result Register 6 Low
7 6 5 4 3 2 1 0
Bit symbol
ADR61
ADR60
ADR6RF
ADREG6L
(12ACH)
Read/Write R
R
After
reset
Undefined 0
Function
Stores lower 2 bits of AD
conversion result.
AD conversion
data storage
flag
1:Conversion
result stored
AD Conversion Result Register 6 High
7 6 5 4 3 2 1 0
Bit symbol
ADR69
ADR68
ADR67 ADR66 ADR65 ADR64 ADR63 ADR62
ADREG6H
(12ADH)
Read/Write R
After
reset
Undefined
Function
Stores upper 8 bits of AD conversion result.
AD Conversion Result Register 7 Low
7 6 5 4 3 2 1 0
Bit symbol
ADR71
ADR70
ADR7RF
ADREG7L
(12AEH)
Read/Write R
R
After
reset
Undefined 0
Function
Stores lower 2 bits of AD
conversion result.
AD conversion
data storage
flag
1: Conversion
result
stored
AD Conversion Result Register 7 High
7 6 5 4 3 2 1 0
Bit symbol
ADR79
ADR78
ADR77 ADR76 ADR75 ADR74 ADR73 ADR72
ADREG7H
(12AFH)
Read/Write R
After
reset
Undefined
Function
Stores upper 8 bits of AD conversion result.
7
6
5
4
3
2
1
0
7
6
5
4
3
2
1
0
Figure 3.11.7 Register for AD Converter
9
8
7
6
5
4
3
2
1
0
Channel
× conversion
result
ADREGxL
•
Bits 5 to 1 are always read as 1.
• Bit0 is the AD conversion data storage flag
AD conversion result is stored, the flag is set to 1. When either of the
registers (ADREGxH, ADREGxL) is read, the flag is cleared to 0.
