TMP92CM22
2007-02-16 92CM22-33
Default Priority Type Interrupt Source
Vector
Value
Address
Refer to
Vector
Micro DMA
Start Vector
52 INTAD: AD conversion end 00CCH FFFFCCH 33H
53 INTTC0: Micro DMA end (Channel 0) 00D0H FFFFD0H 34H
54 INTTC1: Micro DMA end (Channel 1) 00D4H FFFFD4H 35H
55 INTTC2: Micro DMA end (Channel 2) 00D8H FFFFD8H 36H
56 INTTC3: Micro DMA end (Channel 3) 00DCH FFFFDCH 37H
57 INTTC4: Micro DMA end (Channel 4) 00E0H FFFFE0H 38H
58 INTTC5: Micro DMA end (Channel 5) 00E4H FFFFE4H 39H
59 INTTC6: Micro DMA end (Channel 6) 00E8H FFFFE8H 3AH
60 INTTC7: Micro DMA end (Channel 7) 00ECH FFFFECH 3BH
Maskable
(Reserved) 00F0H
:
00FCH
FFFFF0H
:
FFFFFCH
−
Note 1 : When initiating initiating micro DMA, set at edge detect mode.
Note 2 : Micro DMA default priority.
Micro DMA initiation takes priority over other maskable interrupts
