AD converter (2/2)
Symbol Name Address 7 6 5 4 3 2 1 0
ADR41 ADR40 ADR4RF
R R ADREG4L
AD result
register 4
low
12A8H
Undefined 0
ADR49 ADR48 ADR47 ADR46 ADR45 ADR44 ADR43 ADR42
R ADREG4H
AD result
register 4
high
12A9H
Undefined
ADR51 ADR50 ADR5RF
R R ADREG5L
AD result
register 5
Low
12AAH
Undefined 0
ADR59 ADR58 ADR57 ADR56 ADR55 ADR54 ADR53 ADR52
R ADREG5H
AD result
register 5
high
12ABH
Undefined
ADR61 ADR60 ADR6RF
R R ADREG6L
AD result
register 6
low
12ACH
Undefined 0
ADR69 ADR68 ADR67 ADR66 ADR65 ADR64 ADR63 ADR62
R ADREG6H
AD result
register 6
high
12ADH
Undefined
ADR71 ADR70 ADR7RF
R R ADREG7L
AD result
register 7
low
12AEH
Undefined 0
ADR79 ADR78 ADR77 ADR76 ADR75 ADR74 ADR73 ADR72
R ADREG7H
AD result
register 7
high
12AFH
Undefined
