12−8

12.10 Subsystem Identification Register

The subsystem identification register, used for system and option card identification purposes, may be required for
certain operating systems. This read-only register is initialized through the EEPROM and can be written through the
subsystem access register at PCI offset 8Ch (see Section 12.23). All bits in this register are reset by GRST only.

Bit

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

0

Name

Subsystem identification

Type

RU

RU

RU

RU

RU

RU

RU

RU

RU

RU

RU

RU

RU

RU

RU

RU

Default

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

Register:

Subsystem identification

Offset:

2Eh

Type:

Read/Update

Default:

0000h

12.11 Capabilities Pointer Register

The power management capabilities pointer register provides a pointer into the PCI configuration header where the
power-management register block resides. Since the PCI power management registers begin at 80h, this read-only
register is hardwired to 80h.

Bit

7

6

5

4

3

2

1

0

Name

Capabilities pointer

Type

R

R

R

R

R

R

R

R

Default

1

0

0

0

0

0

0

0

Register:

Capabilities pointer

Offset:

34h

Type:

Read-only

Default:

80h

12.12 Interrupt Line Register

The interrupt line register is programmed by the system and indicates to the software which interrupt line the SD host
controller has assigned to it. The default value of this register is FFh, indicating that an interrupt line has not yet been
assigned to the function.

Bit

7

6

5

4

3

2

1

0

Name

Interrupt line

Type

RW

RW

RW

RW

RW

RW

RW

RW

Default

1

1

1

1

1

1

1

1

Register:

Interrupt line

Offset:

3Ch

Type:

Read/Write

Default:

FFh
