4−22

Table 4−9. General Control Register Description

BIT

SIGNAL

TYPE

FUNCTION

15 ‡

FM_PWR_CTRL

_POL

RW

Flash media power control pin polarity. This bit controls the polarity of the MC_PWR_CTRL_0 and
MC_PWR_CTRL_1 terminals.

0 = MC_PWR_CTRL_x terminals are active low (default)
1 = MC_PWR_CTRL_x terminals are active high

14 ‡

SC_IF_SEL

RWU

Smart Card interface select. This bit controls the selection of the dedicated Smart Card interface
used by the controller.

0 = EMV interface selected (default)
1 = PCI7x10-style interface selected

Note: The PCI7x10-style interface is only allowed when bits 9−8 (FM_IF_SEL field) are 01. If bits
9−8 contain any other value, then this bit is 0. Care must be taken in the design to ensure that this
bit can be set to 1 at the same time that bits 9−8 are set to 01.

13 ‡

SIM_MODE

RW

When this bit is set, it reduces the query time for UltraMedia card types.

0 = Query time is unaffected (default)
1 = Query time is reduced for simulation purposes

12 ‡

IO_LIMIT_SEL

RW

When this bit is set, bit 0 in the I/O limit registers (PCI offsets 30h and 38h) for both CardBus functions
is set.

0 = Bit 0 in the I/O limit registers is 0 (default)
1 = Bit 0 in the I/O limit registers is 1

11 ‡

IO_BASE_SEL

RW

When this bit is set, bit 0 in the I/O base registers (PCI offsets 2Ch and 34h) for both CardBus functions
is set.

0 = Bit 0 in the I/O base registers is 0 (default)
1 = Bit 0 in the I/O base registers is 1

10 ‡

12V_SW_SEL

RW

Power switch select. This bit selects which power switch is implemented in the system.

0 = A 1.8-V capable power switch (TPS2228) is used (default)
1 = A 12-V capable power switch (TPS2226) is used

9−8 ‡

FM_IF_SEL

RW

Dedicated flash media interface selection. This field controls the mode of the dedicated flash media
interface.

00 = Flash media interface configured as SD/MMC socket + MS socket (default)
01 = Flash media interface configured as 2-in-1 (SD/MMC, MS) socket
10 = Flash media interface configured as 3-in-1 (SD/MMC, MS, SM/XD) socket
11 = Reserved

7 ‡

DISABLE_SC

RW

When this bit is set, the Smart Card function is completely nonaccessible and nonfunctional.

6 ‡

DISABLE_SD

RW

When this bit is set, the SD host controller function is completely nonaccessible and nonfunctional.

5 ‡

DISABLE_FM

RW

When this bit is set, the flash media function is completely nonaccessible and nonfunctional.

4 ‡

DISABLE_SKTB

RW

When this bit is set, CardBus socket B (function 1) is completely nonaccessible and nonfunctional.

3 ‡

DISABLE_OHCI

RW

When this bit is set, the OHCI 1394 controller function is completely nonaccessible and nonfunctional.

2 ‡

DED_SC_PWR_

CTRL

RW

Dedicated Smart Card power control. This bit determines how power to the dedicated Smart Card
socket is controlled.

0 = Controlled through the SC_PWR_CTRL terminal (default)
1 = Controlled through the VPP voltage of socket B of the CardBus power switch (the design

must ensure that this mode can only be set when CardBus socket B is disabled).

1−0 ‡

ARB_CTRL

RW

Controls top level PCI arbitration:

00 = 1394 OHCI priority

10 = Flash media/SD host priority

01 = CardBus priority

11 = Fair round robin

Note: When flash media/SD host priority is selected, there must be a two-level priority scheme with the
first level being a round robin between the flash media and SD host functions and the second level being
a round robin between the CardBus and 1394 functions.

‡ These bits are cleared only by the assertion of GRST.
