6F3B0253
294
T1-16S User’s Manual
Appendix
A.1 List of models and types
•
Basic unit
Model Power supply Input type RTC/RS-485 Type code Part number
Yes T1-MDR16SS TDR116S6S 100 – 240Vac
No T1-MDR16SC TDR116S6C
Yes T1-MDR16SSD TDR116S3S
T1-16S
24Vdc
24Vdc
No T1-MDR16SCD TDR116S3C
•
I/O module
Description Type code Part number
16 points 24Vdc input DI116M TDI116M
∗
S
16 points 24Vdc output DO116M TDO116M
∗
S
8 points 24Vdc input and 8 points 24Vdc output DD116M TDD116M
∗
S
8 points relay output RO108M TRO108M
∗
S
1 channel analog input, 0 – 5V/0 - 20mA AD121M TAD121M
∗
S
1 channel analog input,
±
10V AD131M TAD131M
∗
S
1 channel analog output, 0 – 20mA DA121M TDA121M
∗
S
1 channel analog output,
±
10V DA131M TDA131M
∗
S
1 channel thermo couple input, K/E/J TC111M TTC111M
∗
S
TOSLINE-F10 remote station FR112M TFR112M
∗
S
•
Peripherals
Description Type code Part number
Handy programmer (with 2 m cable for T1/T1S) HP911A THP911A
∗
S
T-PDS software (Windows version) T-PDS Windows TMW33E2SS
Program storage module RM102 TRM102
∗∗
S
Multi-drop adapter for computer link CU111 TCU111
∗∗
S
•
Cable and others
Description Type code Part number
T-PDS cable for T1/T1S, 5m length CJ105 TCJ105
∗
CS
HP911A cable for T1/T1S, 2m length (spare parts) CJ102 TCJ102
∗
CS
RS-232C connector for computer link
(with 2 m cable) PT16S TPT16S
∗
AS
I/O module I/O connector for
DI116M/DO116M/DD116M, soldering type PT15S TPT15S
∗
AS
I/O module I/O connector for
DI116M/DO116M/DD116M, flat cable type PT15F TPT15F
∗
AS
