4-34 Configuring Your Server

Operating Procedures for Setup Utility

Creating/Adding Configuration

Run LSI Logic Software RAID Setup Utility

Set new configuration information (pack/logical drive settings)

Check the logical drive settings

Initialize logical drive

Perform Consistency Check

Exit LSI Logic Software RAID Setup Utility

Run LSI Logic Software RAID Setup Utility.

Select "Configure" → "New Configuration" from the TOP menu (Management Menu).
Select "View/add Configuration" to add configuration.

IMPORTANT:

Creating a configuration using "New Configuration" menu clears
the existing configuration information. To add configuration
information to the existing configuration, select "View/add
Configuration."

You cannot create Spanning of RAID1 or set the logical drive
capacity on "Easy Configuration" menu.
Use "New Configuration" or "View/Add Configuration" instead.
