Configuring Your Server 4-37

(5) "Span: Sets Span.

Parameter

Remarks

SPAN=NO

Does not set span.

SPAN=YES

Sets span.

When performing SPAN, create two or more sets of the same pack at pack creation, as
shown in the figure below.

„

ONLIN A00-01

„

ONLIN A00-02

„

ONLIN A01-01

„

ONLIN A01-02

Spanning of RAID1

0

1

2

3

4

5

6

ID

RAID1

SPAN

RAID1

9.

When all settings are completed, select "Accept" and then press Enter to create logical
drive.

The created logical drive is displayed in the "Logical Drive Configured" screen.

10.

After creating logical drive, press Esc to close the screen.

Go back to the "Save Configuration?" screen and then select "Yes" to save the
configuration.

11.

When the confirmation message shows that the configuration has been saved, press Esc
to return to the TOP menu screen.

12.

On the TOP menu screen, select "Objects" → "Logical Drive" → "View/Update

Parameters" to check logical drive information.

13.

Select "Initialize" in the TOP menu screen.

14.

When the "Logical Drives" screen appears, move the cursor to the logical drive to be
initialized, and press Space.

The logical drive is selected.

15.

After selecting logical drive, press F10 to start initialization.

A confirmation screen for execution appears. Select "Yes" to start initialization.

When the progress bar in the "Initialize Logical Drive Progress" screen indicates 100%,
initialization is completed.
