Configuring Your Server 4-17
Peripheral Configuration
The screen shown below appears if you select "Peripheral Configuration" on the Advanced menu. If
you select a menu item preceded by symbol
³
and press Enter, the appropriate submenu appears.
See the table below for the items.
IMPORTANT: Note that the interrupt and/or base I/O address does
not conflict with others. If the value set for the interrupt or base I/O
address is used in another resource, the yellow asterisk (*) appears.
Reassign any item with the yellow asterisk properly.
Option Parameter Description Your Setting
Serial Port A Disabled
[Enabled] Selects whether serial port A is
enabled or disabled.
Base I/O address [3F8]
2F8
3E8
2E8 Selects the base I/O address for serial
port A.
Interrupt IRQ 3
[IRQ 4] Selects the interrupt for a serial port A.
Serial Port B Disabled
[Enabled] Selects whether serial port B is
enabled or disabled (display only).
Base I/O address 3F8
[2F8]
3E8
2E8 Selects the base I/O address for serial
port B.
Interrupt [IRQ 3]
IRQ 4 Selects the interrupt for a serial port B.
USB 2.0 Controller Disabled
[Enabled] Selects whether the USB 2.0 device is
enabled or disabled.
