4-6 Configuring Your Server

Boot

To change the boot order of devices connected to the server

Select [Boot] and specify the boot order.

To control from the remote console

Select [Server] - [Console Redirection] and set each item.

Memory

To check the installed memory (DIMM board) status

Select [Advanced] - [Memory Configuration] and check the status indications.

The on-screen DIMM group numbers and socket locations on the mother board are
associated as shown in the following figure.

To clear the memory (DIMM board) error information

Select [Advanced] - [Memory Configuration] - [Memory Retest] - [Yes] and reboot.

To run power-on memory test

Select [Advanced] - [Memory Configuration] - [Extended RAM Step] - [1MB] and
reboot.

DIMM #B-3
DIMM #B-2
DIMM #B-1
DIMM #A-3
DIMM #A-2
DIMM #A-1

CPU #1

CPU #2

FRONT

REAR

Motherboard
