Page 211
Upgrading Your Server 9-5
INSTALLATION OR REMOVAL PROCEDURE
Install or remove a component from the server in the following procedure.
Left Side Cover
The left side cover should be removed to access to built-in devices in the server.
Removal
Remove the left side cover in the following procedure.
1.
See the section "Preparing for Installation and Removal" described earlier to prepare.
2.
Unlock the left side cover if required.
3.
Fold the four stabilizers at the bottom of the server toward inside.
