10-2 Internal Cabling Diagrams
INTERFACE CABLES
This section describes the connections of the interface cables.
Addition of Hard Disk Drive
The connection required when a hard disk drive is added is described below.
Installation of SAS Disks
If the SAS hard disk drives are added, connect the cables as shown in the figure below. Fill the drive
bay with the hard disk drives from the bottom to top bay.
5.25-inch device bay
Fourth
hard disk drive
HDD cage
DVD-ROM drive
Power
supply
Mother board
IDE cable
SAS cable
Third
hard disk drive
Second
hard disk drive
First
hard disk drive
