Configuring Your Server 4-5
Configuration Examples
The following describes examples of configuration required to use software-link features or for
system operations.
Time and Date Settings
You can also change the time and date settings via the operating system commands.
Select [Main] - [System Time].
Select [Main] - [System Date].
Link with Management Software
To control power supply of the server with NEC ESMPRO Manager via the network
Select [Advanced] - [Advanced Chipset Control] - [Wake On LAN/PME] - [Enabled].
Select [Server] - [AC LINK] - [Stay Off].
Hard Disk Drive
To check the hard disk drive status
Select [Main] - [Primary IDE Master] and check the status indications.
To configure the SW RAID (on-board) with SATA hard disk drives
Select [Advanced] - [Peripheral Configuration] - [SATA Controller Mode Option] -
[Enhanced]. Then select [Advanced] - [Peripheral Configuration] - [SATA RAID] -
[Enabled], and configure the RAID drive.
IMPORTANT: Be sure to set to [Enabled] after executing [Load
Setup Defaults] or CMOS clear. Leaving this parameter as the factory-
set value (Disabled) may destroy the data in hard disk drive.
UPS
To link power supply with the UPS
„ To power on the server when power is supply from the UPS
Select [Server] - [AC LINK] - [Power On].
„ To keep the server off-powered even when power is supplied from the UPS
Select [Server] - [AC LINK] - [Stay Off].
„
To keep the server off-powered even when power is supplied from the UPS if the POWER
switch was used to power off
Select [Server] - [AC LINK] - [Last State].
