Upgrading Your Server 9-49
Installation
Install a file device in the following procedure. Explanations are for factory-installed file bay.
Explanation specific for hard disk drive installing kit is also described.
SCSI Device
1. Provide the proper setting for the device.
See the table below for the settings of the devices which can be installed in the device bay.
Device Setting
SCSI device Termination resistance: OFF*
* If the terminator is not connected to the optional internal SCSI cable, set the termination
resistance to ON.
IMPORTANT: SCSI ID for the device you are installing must be
unique.
2. See the section "Preparing for Installation and Removal" described earlier to prepare.
3. Remove the left side cover and front mask as described earlier in this chapter.
NOTE: If you are going to install the hard disk drive device bay
conversion kit, remove the dummy cover from the additional slot 2.
4. Remove the two screws securing the dummy cover of the additional slot 1.
IMPORTANT: Keep the removed dummy cover for future use.
