Upgrading Your Server 9-35
Group#1
Group#2
Group#3
Memory Controller 0
Each group has must have
the same capacity
The memory group farthest from the memory controller is specified as spare memory.
NOTES:
„ If both Group #1 and Group #2 contain DIMMs, the Group #2 is
specified as spare memory.
„ If all groups contain DIMMs, the Group #3 is specified as spare
memory.
You may install DIMMs in the memory controller 1 in the similar way as the memory
controller 0.
The capacity of physical/logical memory is calculated for each controller.
