Maintenance 7-9

6.

Select [System Diagnostics].

The system diagnostics starts and will be completed in approximately three minutes.
When the diagnostics is completed, the screen of the display changes as shown below:

Diagnostics tool title

[Enter] Detail Information [ESC] Return to Enduser Menu

Test End

TeDoLi (TEst & Diagnosis On Linux) Ver001.00 (Build020901.1.1m)

MEM

Memory

16 count

NormalEnd

CACHE

Cache

49 count

NormalEnd


HDD_02:000 DK32DJ-36W

89 count

NormalEnd

Start 10:06:58 End 10:09:58 Pass 000:03:00 TestTime 000:03:00
Test End : NormalEnd 03 AbnormalEnd 00 ForceEnd 00

Guide line

Test summary window

Test result

Test window title

– Diagnostics tool title

Shows the name and version of the diagnostic tool.

– Test window title

Shows the progress of the diagnostics. "Test End" is displayed when the diagnostics
completes.

– Test result

Shows the start, end, and elapsed time and completion status of the diagnostics.

– Guide line

Shows the details of the keys to operate window.

– Test summary window

Shows the results of each test that executed the diagnostics. Move the cursor and
press the Enter key on the cursor line to display the details of the test.

When an error is detected by the system diagnostics, the relevant test result in the test
Summary window is highlighted in red, and "Abnormal End" is displayed in the result on
the right side.

Move the cursor to the test that detected the error, and press the Enter key. Record the
error message that has been output to the Detail Information screen and contact your
service representative.
