Upgrading Your Server 9-25
SATA Model
Slot
(Bus A)
Slot
(Bus B)
Slot
(Bus C)
Slot
(Bus D)
Slot
(Bus E) Product name
PCIe #1 PCI-X #2 PCIe #3 PCIe #4 PCI #5
PCI slot capability *1 x4 lane
64 bit/
100MHz
x8 lane x1 lane
32 bit/
32MHz
Slot size Full-height
PCI board type *1
x4
socket
3.3V
x8
socket
x4
socket
5V
N code
Available board size Short Long/short
Note
N8103-95
SCSI controller
(64-bit/66MHz PCI)
– √ – – √
2 max.
Cannot connect with internal
hard disk drive.
N8103-75
SCSI controller
(64-bit/133MHz PCI-X)
– √ – – √
2 max.
Cannot connect with internal
hard disk drive.
N8103-126
SCSI controller
(64-bit/133MHz PCI-X)
– √ – – √
2 max.
Cannot connect with internal
hard disk drive.
For connection with SATA
disk array
N8103-101
Disk array controller
(SATA2)
(PCI EXPRESS (x4))
√ – √ √ – 1 max.
N8103-103
Disk array controller
(SATA2)
(PCI EXPRESS (x4))
√ – √ √ – 1 max.
N8103-102
Additional battery for
N8103-101
√ √ √ √ √ 1 max.
N8103-80
Disk array controller (1 ch)
(64-bit/66MHz PCI)
– √ – – √
1 max.
Cannot connect with internal
hard disk drive.
2 max. with N8103-81/86
N8104-111
100BASE-TX adapter
(32-bit/33MHz PCI)
– √ – – √ 2 max.
N8104-86
100BASE-TX adapter
(32-bit/33MHz PCI)
– √ – – √ 2 max.
N8104-119
1000BASE-T adapter
(64-bit/133MHz PCI-X)
– √ – – √
N8104-120
1000BASE-T adapter (2 ch)
(64-bit/133MHz PCI-X)
– √ – – √
1 max. per PCI bus (2 max.
per PCI bus with AFT)
N8104-120: 2 max. per
system
Cannot co-exist with N8104-
112.
N8104-114
1000BASE-T adapter
(PCI EXPRESS (x1))
√ – √ √ –
2 max.
Teaming with another N8104-
114 is allowed.
N8104-121
1000BASE-T adapter (2ch)
(PCI EXPRESS (x4))
√ – √ √ – 2 max.
N8104-112
1000BASE-SX adapter
(2ch)
(64-bit/133MHz PCI-X)
– √ – – √
1 max. per PCI bus (2 max.
per PCI bus with AFT)
Cannot co-exist with N8104-
103/113.
N8104-123A
10GBASE-SR adapter
(PCI EXPRESS (x8))
– – √ – – 1 max.
N8105-45
Graphics accelerator
(32-bit/33MHz PCI)
– √ – – √ 1 max.
N8117-01A
Additional RS232C
connector kit
– – – √ √ 1 max.
√: Available, –: Unavailable
