Upgrading Your Server 9-23
PCI Board
The server is equipped with five slots for installing PCI boards.
IMPORTANT:
„ Any PCI board is easily affected by static electricity. Handle a PCI
board after making your body contact with a metallic frame section
of the server to discharge the static electricity on your body. Do not
make bare hands contact with terminals and components on the PCI
board. In addition, do not put the PCI board on a desk directly. See
"Static Precautions" in this chapter for details of the static
electricity.
„
The long-sized board (full-length board) can be installed only to the
PCI slot #2. Care must be taken to avoid damage to the components
on the mother board when installing the long-sized board.
Mother board
PCI board slot #1
PCI board slot #2
PCI board slot #3
PCI board slot #4
PCI board slot #5
