background image

Specifications A-5

SAS Model (N8100-1237F/1238F/1323F/1324F)

NEC Express5800/120Eh

Item

N8100-1237F

N8100-1238F

N8100-1323F

N8100-1324F

Type

Dual-core Intel Xeon Processor

Clock / Cache

1.6G/1066/4M

3G/1333/4M

2G

/

1066

/

4M

2.33G/1066/4M

Number of processors

1

CPU

Maximum

2

Chipset

Intel Blackford-VS + ESB2E + ServerEngines Pilot

Standard

1GB (512 MB × 2)

Maximum

24 GB (4 GB × 6)

Expansion unit

2 DIMMs (512MB×2/1GB×2/2GB×2/4GB×2)

Expansion times

2 times

Memory module

DDR2-533/667 SDRAM DIMM (Fully Buffered Type), Dual channel
memory configuration supported)

Memory

Error check

ECC, ChipKill, Sparing

Graphics (VRAM)

Matrox G200 + 2MB

Floppy disk drive (standard) None
Hard disk drive (standard)

None

Hard disk drive (maximum) SAS (146GB x 4)
Hard disk drive (hot-plug)

Hot Plug SAS HDD x 4

Auxiliary
input device

DVD-ROM (standard)

DVD-ROM x 1 (load on tray, x6 speed or faster)

5.25-inch file bay

3 slots (A DVD-ROM drive is factory-installed.)

3.5-inch disk bay

1-inch height x4 (SAS HotPlug)

Additional PCI slot

5 slots (PCI Express (x8) x1, PCI Express (x4) x1, PCI Express (x1)
x1, 64-bit/100MHz PCI-X x1, 32-bit/33MHz PCI x1

Standard

On-board SAS SW RAID (0,1)

Disk array

Option

Disk array controller

IDE (single unit)

Ultra ATA100 x1ch

SATA (single unit)

SATA (disk Array)

SCSI (single unit)

Option (for tape unit with N8103-75/95)

SCSI (external Disk Array)

Option (Supports N8103-80/81 (up to 2, SAS DAC (SW/HW) may be
installed together)

SAS (single unit)

4i connector x1 + 2ch

SAS (internal Disk Array)

Supports N8103-91/99 (either one)

Internal
interface

SAS (external Disk Array)

Supports N8103-90 (up to 3 including N8103-91/99)

Front

USB2.0 x2

External
interface

Rear

VGA x1, KB (PS/2) x1, Mouse (PS/2) x1, Serial x1, USB2.0 x2,
10/100/1000BASE-T x2, 10/100BASE-TX x1 (100BASE-TX is used
for management)

Cabinet design

Mini tower

External dimensions

198 (width) × 440 (height) × 518 (depth) mm

Weight

16 kg (Max. 23 kg)

Power supply

100 to 120 Vac/200 to 240 Vac parallel bi-polar receptacle with the
ground line

Power consumption

550 VA, 545 W

Switch

Power/Sleep (front), Dump (rear)

Security key

Provided

LED

Power/Sleep, HDD (front), LAN x3 (rear)

Temperature

10 to 35°C (operating), -10 to 55°C (non-operating, storage)

Environmental
requirements

Humidity

20 to 80% RH (no condensation)
