User’s Manual of SGSD-1022 / SGSD-1022P
SGSW-2840 / SGSW-2840P
305
Object Description
Network Access MAC
Address Count
The number of MAC addresses currently in the secure MAC address table.
Query By Specifies parameters to use in the MAC address query.
Port Specifies a port interface.
MAC Address Specifies a single MAC address information.
Attribute Displays static or dynamic addresses.
Address Table Sort Key Sorts the information displayed based on MAC address or port interface.
Unit/Port The port interface associated with a secure MAC address.
MAC Address The authenticated MAC address.
RADIUS Server The IP address of the RADIUS server that authenticated the MAC address.
Time The time when the MAC address was last authenticated.
Attribute Indicates a static or dynamic address.
Remove Click the Remove button to remove selected MAC addresses from the secure
MAC address table.
