Page 133
The Test Signals Function
Setting up your Monitor 3-59
S
e
tt
ing up y
our
M
onit
o
r
Procedure
1. Press hardkey
2. Press softkey
i
n the Instrument Configuration
Selection Window.
The monitor returns to Main Screen. Test waves for each parameter being
monitored are generated for 30 seconds to test the processing abilities of
the monitor. The message “Test Signals active - no monitoring” appears
on the screen.
After 30 seconds, the monitor automatically switches back to Monitoring
Mode.
If you want to go back to Monitoring Mode before 30 seconds have
elapsed, press
, then
.
Analog
Output
(CMS only)
The Analog Output function provides eight channels of Analog Output for
connection to recorders and other data collection instruments. For more
information on Analog Output, refer to Appendix B.
Monitor Setup
Test Signals
Monitor Setup
Stop Signals
