Selecting Realtime Wave Speeds
3-16 Setting up your Monitor
S
e
tt
ing up y
our
M
onito
r
Press the softkey to return to the Display Setup
Window, press to return to the Selection Window or
to return to the Main Screen.
To select the same speed for all the waveforms:
1. Press repeatedly to select the speed you require.
2. Press the softkey to return to the Realtime
Waves Task Window, press to return to the
Selection window or to return to the Main Screen.
Note—
• The speed of the Resp or CO
2
waves and of the AG waves must
always be set individually. You cannot alter their speeds by
pressing .
• If waves overlap, all the waves travel at the speed of the wave in
the first overlapping channel. If the overlap is then changed to
non-overlapping waves each wave travels at its assigned speed.
